Single Driving High Pressure Roller Mill-Series PGM

Single Driving High Pressure Roller Mill-Series PGM

Type: Complete Set of Mining Equipment
Patent number:
Service hotline:400-658-3198
send e-mail:    raul@chinahuate.com
  • Applicable Scope
The Single Driving High Pressure Roller Mill - Series PGM is specially designed to pre-grind the cement clinkers, the mineral dross, the steel clinkers and so on into small granules, to ultra-crush the metallic minerals (iron ores, manganese ores, copper ores, lead-zinc ores, vanadium ores and others) and to grind the non-metallic minerals (the coal gangues, feldspar, nepheline, dolomite, limestone, quartz, etc.) into the powder.
  • Technical Features

1. High Working Efficiency

Compared with the traditional crushing equipment, the processingcapacity increases by 40 - 50%. The processing capacity for PGM1040 can reacharound 50 -100 t/h, with only 90kw power.

2. Low Energy Consumption

As per the single roller driving way, it needs only one motor todrive. The energy consumption is very low. Compared with the traditional doubledriving roller mill, it can reduce the energy consumption by 20~30%.

3. Good Wear-resistant Quality

With only one motor driving, the synchronization performance ofthe two rollers is very good. With wear-resistant welding surfaces, the rollersare with good wear-resistant quality and can be easily maintained.

4. High Operation Rate: 95%

With scientific design, the equipment can be pressurized by thehigh pressure spring group. The working pressure can be adjusted automaticallyas per the spring group compress. There is no malfunction point.

5. High Automation and easyadjustment. Without the hydraulic system, there is low malfunction rate

6. Long Service Life

7.Simple and Compact Structure


IV. Technical Parameters:




Model

Roller Φ mm

Roller Width mm

Maximum Feed-in Size for Cement Steel Clinker  Mineral Dross mm

Perfect Feed-in Size for Metallic & Non-metallic Mineral mm

Feed-out Size for Cement mm

Processing Capacity t/h

Motor Power kw

Overall Dimensions L*W*H mm

PGM0850

800

500

50







30







Classify,<4

30~40

75

2760X2465X1362

PGM1040

1000

400

Classify,<4 (<2.5:75%)

50~80

90

4685x4100x2020

PGM1060

1000

600


70~110

110

4685x4300x2020

PGM1065

1000

650


100~160

200

5560x4500x2200

PGM1250

1200

500

Classify,<4

(<2: 80%)

120~180

250

6485x4700x2485

PGM1465

1400

650


240~320

630

9200x6320x3600

PGM16100

1600

1000

V Separation,<1

500~650

1250

10800x8100x4400
