Series RCSC Superconducting Iron Separator
Type: Superconducting EquipmentService hotline:400-658-3198
send e-mail: raul@chinahuate.com
- Applicable Scope
Magneticfield intensity can reach 50000Gs.With highmagnetic force, deep magnetic effective depthLigh
- Technical Features
Magneticfield intensity can reach 50000Gs.
With highmagnetic force, deep magnetic effective depth
Lightweight ,low energy consumption
Reliable operation , environment protection.
Major Technical Parameter:
Belt width mm | 1600 | 1800 | 2000 | 2200 | 2400 |
Suspension height mm | 450 | 500 | 550 | 600 | 650 |
Rated suspension magnetic field intensity | 400 | ||||
Magnetic intensity at the iron separator bottom ≥ mT | 2000 | ||||
Exciting power ≤kW | 30 | ||||
Dimension mm | Φ 1800*1900 | Φ 2000*2100 | Φ 2300*2350 | Φ 2500*2600 | Φ 2700*2800 |
Unit Weight Kg | 6700 | 7200 | 8000 | 9500 | 11000 |
