ZPG Disk vacuum filter
Type: Complete Set of Mining EquipmentService hotline:400-658-3198
send e-mail: raul@chinahuate.com
- Applicable Scope
ZPG Disk vacuum filter is a solid-liquid separation equipment, filter disks is driven by adjustable
- Technical Features
ZPG Disk vacuum filter is a solid-liquid separation equipment, filter disks is driven by adjustable speed motor through speed reducer and exposed gear ,make it in the filled full pulp tank to rotate in a some speed。
Technical Parameter:
filter diameter (mm) | 2100 | 3100 | |||||||||||||||||
filter area(m㎡) | 10 | 15 | 20 | 25 | 30 | 35 | 40 | 48 | 60 | 72 | 80 | 96 | |||||||
filter disk number | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 4 | 5 | 6 | 7 | 8 | |||||||
each disk filter fan quantity | 20 | ||||||||||||||||||
Spindle motor power | 2.2 | 3 | 4 | 5.5 | 7.5 | ||||||||||||||
Stirrer motor power | 3 | 4 | 5.5 | 7.5 | 11 | ||||||||||||||
appearance | L(mm) | 2535 | 2920 | 3315 | 3705 | 4095 | 4485 | 4875 | 4235 | 4735 | 5235 | 5735 | 6235 | ||||||
W(mm) | 2480 | 4205 | |||||||||||||||||
H(mm) | 2690 | 3700 | |||||||||||||||||
Discharge method | Reverse blowing | ||||||||||||||||||
Capacity(t/m2/h) | 0.6~0.85 |
